The Stahlhelm


The Imperial German M16, M17 & M18 Stahlhelme

The M16 Stahlhelm
Although Imperial Germany may have been the last of the major powers to introduce a steel helmet, the Stahlhelm was undoubtedly the best-designed helmet of the Great War. While other helmets can sometimes give the impression of war hats, the Stahlhelm is truly a helm in every sense of the word. Reminiscent of the samurai kabuto, it is also not difficult to see more than a little inspiration for a certain well-known Sith Lord. Perhaps no other helmet is as intimidating, dramatic and thoroughly evocative. The market for German helmets has always been strong, which in other words means that as a new collector you’re about to have your mettle tested –and in more ways than one.
To begin with, there are actually 7 distinct variants of the German Stahlhelm possible to encounter and that you should be aware of, but in practice you will really only ever see three. These are the M16, the M17 and M18. These are collector designations, as the M16 and M17 are identical, save for the liner, and also transitional, i.e., their introduction did not necessarily coincide exactly with a certain calendar year. This is also true somewhat for the M18, although this helmet is easy to recognize even from its outward appearance, which we will discuss later. Furthermore, the Austro-Hungarian Empire also manufactured their own versions of the Stahlhelm: the Austro-Hungarian Models 17 and 18. While these helmets will not be described in detail in this section, I have noted where they differ significantly from the German models.
Vestiges Militaria provides an excellent overview of the history, design, manufacture and variants of the Stahlhelm (en français once again). An example of this helmet is also displayed in the Great War Gallery.

The Manufacturers & Their Sizes
Manufacturer and size information was cold-stamped on the helmet interior and can be found opposite the wearer’s left ear. The following table gives a list of known manufactures, their code, location, sizes produced and approximate production numbers, including their percentage produced as a part of the total production. Note: the validity of the production figures is unverified at this time. (For example, I myself own a Bell L helmet and I feel they are encountered more frequently than these numbers would seem to indicate.)

Stahlhelm Manufacturers and Production Figures, 1916-1918
Code
Manufacturer
Location
Sizes
Production
E.T.
Eisenhüttenwerke Thale A.G.
Thale/Harz
60-68
~ 2.3M (30.9%)
B.F.
F.C. Bellinger
Fulda
62,64
~ 1.4M (18.8%)
Si
Eisenhütte Silesia
Paruschowitz
62,66
~ 1M (14.4%)
T.J.
C. Thiel & Söhne
Lübeck
66,68
~ 660K (8.3%)
Q
Firma F.W. Quist
Esslingen/Neckar
66
~ 540K (7.2%)
G
Gebrüder Gnüchtel A.G.
Lauter i./Sa.
62
~ 500K (6.6%)
W
Hermann Weissenburger & Co.
Stuttgart-Cannstatt
66
~ 290K (3.9%)
G.B.N.
Gebrüder Bing A.G.
Nürnberg
64
~ 250K (3.3%)
S/H
Siemens & Halske A.G.
Siemenstadt Berlin
60
~ 83K (1.1%)
K
J. & H. Kerkmann
Ahlen/Westphalen
64
~ 125K (1.7%)
N.J.
Vereinigte Deutsche Nickelwerke
Schwerte i/Westf.
62
~ 50K (0.7%)
“Bell” L
Richard Lindenberg A.G.
Remscheid-Hasten
64
< 50K (< 0.5%)
K&M
Körting & Mathiesen
Leutsch/Leipzig
68
< 50K (< 0.5%)

Eisenhüttenwerke Thale A.G. (E.T.), F.C. Bellinger (B.F.), and Eisenhütte Silesia (Si) are together known as the Big Three amongst helmet collectors and it seems that 80-90% of helmets you will encounter will be from one of these three manufacturers. Slight variations in form exist between manufacturers, some of which can be quite distinctive, e.g., the longer “duckbill” visor of Gebrüder Bing helmets and the elegantly rounded vent lugs of Lindenberg “Bell L” helmets. As a collector, you may wish to focus on some of the rarer manufacturers or on those whose form you find most appealing. With practice, you may be able to recognize the manufacturer of a given helmet, as well as its size (see Lug Size below) and whether it is an M16/17 or M18, or if it is of Austro-Hungarian origin merely from its visual form.

Lug Size
A defining feature of the Stalhelm are its ventilation lugs, which were meant to serve a dual purpose as an attachment point for a heavy steel front plate known as a Stirnpanzer. As the Stirnpanzer was only manufactured in a single size, the vent lugs needed to be the same distance apart on all helmets, regardless of size. Consequently, these lugs will appear to stick out much farther on helmets of a smaller size; the lugs having more or less of a base until reaching size 66, at which point only the lug itself will be present. Therefore, one can quite easily determine the size of a helmet (i.e., for sizes 60, 62, or 64) from observing the vent lugs.

The Liner
The liner style determines whether a given helmet is designated an M16 or M17 by collectors. M16 helmets have a liner consisting of a band of either a single or double-thickness of brown leather (the latter having 3 seams of stitching holding it together), with liner pads of vegetable-tanned brown leather. M17 (and M18) helmets instead have a band of pressed steel with liner pads generally of white or cream-colored rabbit skin crimped into the liner band.
Behind these leather pads on all models is a canvas pocket containing a small pillow, usually filled with horsehair. They were often removed by the soldiers themselves to adjust the size of the helmet. However, personally, I don’t consider a liner to be truly complete unless they are present.
Liner band stitching: Original (left); Probable fake (right)
Take note that when Stahlhelm liners are faked –and they are– it is most often the single-thickness, leather M16 variety. Examine the leather carefully. After a hundred years, the pad leather will very often have become thin and possess a somewhat paper-like quality. The leather of the liner band will usually be extremely stiff and will probably have shrunk and pulled away slightly from the helmet interior. Liners that have been artificially aged are dirtied-up and sometimes appear to have been brushed with a kind of dye. However, this paper-like quality of old leather is difficult to replicate. If the leather appears too thick or too robust, if none of the tie-string holes have ripped through and especially if the liner band looks too good, it’s a safe bet that it is not an original piece. Also, pay particular attention to the stitching that joins the band to itself, forming the circle. On the inside of the band, this stitching should be horizontal. On the outside of the band, this stitching should criss-cross. This is a detail that is sometimes (though not always) overlooked on faked liners. Austro-Hungarian helmets never utilized a leather liner band, being pressed steel only.

The Chinstrap
Chinstraps were of brown or black leather with buckles and fittings in either brass (earlier helmets) or steel (later helmets). Austro-Hungarian helmets had chinstraps of woven cloth with stitched leather ends. Rather uncharacteristically for the Germans, the chinstrap attachment of the Stahlhelm was poorly designed. The M91 Pickelhaube-style posts proved wholly inadequate for the steel helmet and the chinstrap was frequently lost as a result. Consequently, Stahlhelme with surviving chinstraps are rare, with probably fewer than 5% of M16 and M17 helmets you will find having their original chinstrap and perhaps a slightly higher percentage for M18 helmets, due to their abandonment of this system in favor of direct attachment to the liner. The M91 post rivets are visible on either side of the exterior of the helmet, near the bottom edge of the helmet skirt. Stahlhelme of Austro-Hungarian manufacture are easily distinguished by their much higher positioning of these rivets, nearer the wearer’s temple and it is by the lack of these exterior post rivets that one can easily differentiate the M18 from the M16 and M17 helmets.

The Stahlhelm Variants
The rare Katzenhelm
All of the following design variants can be considered rare and do not often come up for sale. When they do, you can expect to pay a (very) high premium. Though beyond the scope of this site, you should be aware of them and be able to recognize them when you do see them:
  • The M18 Ear Cut-out: The variant most often encountered is the M18 ear cut-out. Watch out for fakes made from authentic helmets that have been altered. The only manufacturer to produce this helmet was Eisenhüttenwerke Thale (E.T.), only in size 64 and it should be marked as such.
  • The “Square-Dip”: The second-most encountered variant you will probably come across is known amongst collectors as the Square-Dip, named for its extremely steep visor-to-skirt transition angle. It was found that this design produced an unacceptable number of structural failures and was therefore quickly amended. As above, the sole manufacturer was Eisenhüttenwerke Thale (E.T.).
  • The Visor-less: Visor-less helmets are often referred to as the Turkish model, which may have been their originally-intended destination. However, very strong evidence suggests that none were ever sent to Turkey, instead being distributed to the Freicorps beginning in 1919. Production is rumored to be 5,400 examples. They do come up for sale from time to time, often with post-war liners and paint.
  • The Full-Visor: Probably the rarest of all German helmets is the so-called Full-visor variant. Essentially, it is the familiar Stahlhelm form, but from the immediate front-edge, the visor takes a steep angle of attack (approximately 70 degrees) to the top of the helmet, rather than the flat-visor-to-90-degree-angled brow on the common helmet. The reasons for the change are not entirely clear, although there is speculation that it could have allowed better clearance for the use of a gasmask or that the increased angle may have better deflected projectiles. There is some discussion regarding this helmet being set to become the standard form had the War continued. This was also the form used as the basis for the Turkish Model 1918 helmet.
Feldgrau & Camouflage Helmets
All German helmets were painted feldgrau –a medium greyish-green color, while Austro-Hungarian helmets were painted brown. Photographic evidence unquestionably supports the use of camouflage-painted helmets by the soldiers of Imperial Germany during the Great War. As the presence of camouflage painting can increase the value of a helmet significantly, any camouflage helmet presented today must be viewed with a healthy degree of skepticism. There is also ample evidence for the painting of captured German helmets as take-home trophies by the victorious Allied troops. In my opinion, camouflage-painted Stahlhelme are generally to be avoided by the new collector for a number of reasons, despite their “wow-factor”. First, a helmet with basic feldgrau paint is important to have as a representative of the piece as it was originally issued and it can allow you to better appreciate its form as a whole. Second, basic feldgrau is not so basic anymore! By that I mean, finding a Stahlhelm with a good, original feldgrau finish is becoming increasingly difficult and these helmets are expensive enough as it is. Lastly, as you become more experienced, you will be in a far better position to be able to distinguish an authentic piece from a modern repaint should you eventually wish to acquire a camouflage helmet.

A Few Words About Latvia
A classic Latvian. Note dull, pitted surface.
I’m sure Latvia is a fine country with fine, upstanding people. However, if you watch eBay for any length of time you will soon discover that there are apparently more “original” 1st Foot Guard Regiment helmets just lying about in Latvia today than all of the members of the 1st Foot Guards had helmets in the Great War. This, obviously, gives some cause for alarm. Latvia represents the very definition of “too good to be true” for the collector. This is especially true of the German helmets –particularly camouflage helmets and rare Garde Regiment helmets— that somehow seem to turn up there every week. Upon close inspection you will often find that these helmets have an extensively pitted surface, whereas the surface of these helmets should be smooth almost without exception. This is indicative of a rusty shell that has been sanded, painted and then given some kind of artificial aging treatment, which often results in these helmets having an unnaturally dull (matte) appearance.
 Reproduction shell. Note low stance and odd visor.
Recently the fakes have become even more audacious, as I have now seen aged repaints of entirely reproduction shells and liners.
Why Latvia? I’m not exactly sure. No doubt there was fighting that took place in Latvia and there must be genuine pieces floating around there somewhere. But the risk is just too great. My advice is: no matter how good it looks, do not buy anything from Latvia, period. I personally have never once seen an authentic piece (excluding battlefield relics) come from this particular country.
